SMD recessed LED down light 5W 8W 12W 15W 20W 25W
| Model |
| |
|
|
|
|
|
| Power |
5W |
8W |
12W |
15W |
18W |
| Light source |
SMD5730 10pcs |
SMD5730 16pcs |
SMD5730 24pcs |
SMD5730 30pcs |
SMD5730 36pcs |
| Luminous flux |
＞450LM |
＞720LM |
＞1100LM |
＞1300LM |
＞1500LM |
| Dimension |
φ90*45mm |
φ110*45mm |
φ140*45mm |
φ160*45mm |
φ180*45mm |
| Cutout |
φ75mm |
φ95mm |
φ115mm |
φ140mm |
φ160mm |
| Parameter |
| |
|
| Input voltage |
100V-240VAC |
| CCT |
3000K/4000K/6000K |
| CRI |
＞80 |
| LED chip |
Epistar |
| Frame color |
white |
| Beam angle |
120° |
| IP grade |
IP44 |
| Material |
Aluminum |
| Life spam |
30000hrs |
| Dimmable |
option |
| Warranty |
3years |
