COB LED down light-10W 15W 20W 30W 40W
| Model |
| |
|
|
|
|
|
| Power |
10W (3inch) |
15W (3.5inch) |
20W (4inch) |
30W (6inch) |
40W (8inch) |
| Light source |
COB 10W |
COB 15W |
COB 20W |
COB 30W |
COB 40W |
| Luminous flux |
＞1000LM |
＞1500LM |
＞2000LM |
＞3000LM |
＞4000LM |
| Dimension |
φ90*55mm |
φ120*65mm |
φ150*78mm |
φ200*105mm |
φ230*120mm |
| Cutout |
φ75mm |
φ100mm |
φ120mm |
φ170mm |
φ200mm |
|
|
|
|
|
|
|
| Parameter |
| |
|
| Input voltage |
100V-240VAC |
| CCT |
3000K/4000K/6000K |
| CRI |
＞80 |
| LED chip |
Bridgelux |
| Frame color |
white |
| Beam angle |
45° |
| IP grade |
IP44 |
| Material |
die-cast aluminum |
| Life spam |
30000hrs |
| Dimmable |
option |
| Warranty |
3years |
| |
|
